Overview
The project description window allows you to configure various elements of your project. This window includes the following tabs:
  • The "Project" tab that is used to type the main project information.
  • The "Analysis" tab that is used to associate an analysis with the project and/or with a UML model.
  • The "Files" tab that is used to type information about the data files managed by the application (only if the project is linked to an analysis).
  • The "Live data" tab that is used to configure the display of data (coming from the data files) in the different editors.
  • The "Languages" tab that is used to configure the different languages handled by the project as well as the linguistic options that will be used for each language.
  • The "Style" tab that is used to choose the theme of skin template and the custom style sheet, and to customize the print preview. You also have the ability to configure the size of screens.
  • The "Group" tab that is used to manage the teamwork (developer groupware or SCM).
  • The "Options" tab that is used to configure the options for updating, saving and synchronizing the templates. This tab is also used to enable the strict mode and to define the code style.
  • The "Advanced" tab that is used to manage the use of "Reports & Queries", the AAFs and the application lock.
  • The "Compilation" tab that is used to configure the compilation options.
  • Versions 22 and later
    The "Telemetry" tab that is used to configure the telemetry options for the project.
    New in version 22
    The "Telemetry" tab that is used to configure the telemetry options for the project.
    The "Telemetry" tab that is used to configure the telemetry options for the project.
Remark: From version 19, HFSQL is the new name of HyperFileSQL.
Style tab

Project skin template

The "Style" tab of the project description window allows you to identify and define the skin template used by the project. A preview shows the skin template in use.
Remark: If the skin template is modified via the project description window, this modification is only taken into account for new windows. To apply an skin template to existing windows, go to the "Project" pane, "Other actions" group, and click "Apply a skin template to the project".
The option "Customize the system windows (Info, YesNo, Confirm, Dialog)" is used to customize system information windows. For more details, see Customizing the system information windows (or dialog boxes).
The option "Apply the theme of skin template to the components included in the project and to the AAF windows" makes it possible to use the theme of the project skin template on all the elements that are included in the project: components, specific AAF windows, etc.
Versions 26 and later
The "Tooltip" option is used to define how to display tooltips in your application. By default, the display mode is "Standard". You can customize the tooltips of the application. For more details, see Custom tooltips.
New in version 26
The "Tooltip" option is used to define how to display tooltips in your application. By default, the display mode is "Standard". You can customize the tooltips of the application. For more details, see Custom tooltips.
The "Tooltip" option is used to define how to display tooltips in your application. By default, the display mode is "Standard". You can customize the tooltips of the application. For more details, see Custom tooltips.

Style sheet

This option allows you to select the style sheet(s) associated with the project.
See also
Minimum version required
  • Version 10
